Mótar Sciathán Seasta 3530EVO

● Meáchan: 75.1g (Sreanga san áireamh)
● Mótair Méid: 35.3 x30mm
● Méid seafta: 5.0*47.5mm
● Trastomhas Stator: 28mm
● Airde Stator: 8mm
● Gluaisteán: 19*25mm(M3*4)
● Cumraíocht: 12N14P
● Luach KV: 1100KV, 1400KV, 1700KV nó KV saincheaptha
Seo a leanas réamhrá ar Mótar Sciathán Seasta D3530EVO, tá súil agam cabhrú leat Mótar Sciathán Seasta D3530EVO a thuiscint níos fearr. Fáilte roimh chustaiméirí nua agus sean chun leanúint ar aghaidh ag comhoibriú linn chun todhchaí níos fearr a chruthú le chéile!

Mionsamhail:D3530EVO

Seol Fiosrúchán

Cur síos ar an Táirge

D3530 EVO Iarratas Mótair DC Brushless

Maidir le Mótar Sciathán Seasta 3530EVO, tá imní speisialta difriúil ag gach duine faoi, agus is é an rud a dhéanaimid ná ceanglais táirge gach custaiméara a uasmhéadú, agus mar sin tá go leor custaiméirí glactha go maith ag cáilíocht ár Mótar Sciathán Seasta 3530EVO agus taitneamh as dea-cháil i. go leor tíortha. Tá dearadh tréithiúil & feidhmíocht phraiticiúil & praghas iomaíoch ag Flash Hobby 3530EVO Fixed Wing Motor, le haghaidh tuilleadh eolais ar an Mótar Sciathán Seasta 3530EVO, bíodh leisce ort teagmháil a dhéanamh linn. D3530EVO (2808) Mótar DC gan scuab le haghaidh Cradle Héileacaptar Meaisín Caife Meaisín Tae Bainne meaisín druileála leictreach meaisín gearrtha lámh robotic

Gnéithe Mótair 3530 EVO Brushless DC
Maighnéad Leibhéal 48H
Tástáil Rotor Chothromaithe Bheachtais
Dearadh Mótair Ard-chasmhóiminte 14P12N
Cloigín Alúmanam CNC 6061-T6
Imthacaí Ard RPM Iompórtáilte (NSK/NMB).

Foirceannadh Sreanga Copar Frithsheasmhach in Ardteocht

3530 Sonraíocht Mótair DC Brushless EVO

Meáchan: 55.7g (Sreanga san áireamh)
Méid Mótair: 28 x26mm
Méid seafta: 3.0*41.0mm
Gluaisteán: 16*19mm(M3*4)
Cumraíocht: 12N14P

Luach 3530 EVO KV don Roghnú

Luach KV: 1100KV, 1400KV, 1700KV nó KV saincheaptha

KV: 1100KV
Uasmhéid vata: 380W
Uasmhéid Reatha: 23.27A
Gan ualach reatha: 1.16A/10V
Friotaíocht: 97.5mΩ
Battery: 3-4S Lipo
Molta: prop 8 orlach

KV: 1400KV
Uasmhéid vata: 663W
Uasmhéid Reatha: 42.97A
Gan ualach reatha: 1.77A/10V
Friotaíocht: 54.4mΩ
Battery: 3-4S Lipo
Molta: prop 8 orlach

KV: 1700KV
Uasmhéid vata: 702.5W
Uasmhéid Reatha: 44.92A
Gan ualach reatha: 2.48A/10V
Friotaíocht: 34.3mΩ
Battery: 3-4S Lipo
Molta: prop 7 orlach

Líníocht Mótair 3530 EVO:

Sonraí Tástála Mótair Gan Scuab D3530 EVO RC

SONRAÍ TEICNIÚLA MOTOR:
Níl.	Volta(V)	Prop	Throttle (%)	REATHA (A)	Cumhacht(W)	Séimhiú (g)	PRM	Éifeachtúlacht (g/W)	Oibriúcháin teocht (℃)
D3530-1100KV(EVO)	12.45	7×5	40%	3.10	38.6	221	6162	5.7	37.2℃
	12.43		50%	4.21	52.3	284	6874	5.4
	12.41		60%	5.30	65.8	311	7441	4.7
	12.38		70%	6.63	82.1	373	8097	4.5
	12.34		80%	8.83	109.0	436	8941	4.0
	12.28		90%	11.62	142.7	519	9862	3.6
	12.26		100%	13.00	159.4	565	10156	3.5
	12.82	APC8x6	40%	3.33	42.7	264	6299	6.2	38.3℃
	12.75		50%	4.53	57.8	331	7043	5.7
	12.60		60%	5.80	73.1	393	7639	5.4
	12.45		70%	7.36	91.6	446	8323	4.9
	12.43		80%	9.93	123.4	555	9178	4.5
	12.40		90%	13.29	164.8	670	10060	4.1
	12.33		100%	14.75	181.9	715	10347	3.9
	16.86	7×5	40%	4.65	78.4	352	7799	4.5	39.1℃
	16.75		50%	6.45	108.0	433	8691	4.0
	16.70		60%	8.35	139.4	513	9496	3.7
	16.50		70%	10.82	178.5	627	10363	3.5
	16.45		80%	14.86	244.4	753	11467	3.1
	16.32		90%	19.51	318.4	929	12467	2.9
	16.22		100%	21.52	349.1	958	12764	2.7
	16.77	APC8x6	40%	4.71	79.0	390	7660	4.9	39.6℃
	16.70		50%	6.56	109.6	477	8590	4.4
	16.65		60%	8.69	144.7	582	9370	4.0
	16.50		70%	11.44	188.8	695	10227	3.7
	16.48		80%	15.92	262.4	877	11264	3.3
	16.43		90%	21.12	347.0	1021	12125	2.9
	16.36		100%	23.27	380.7	1080	12349	2.8
D3530-1400KV(EVO)	12.39	7×5	40%	5.52	68.4	296	7357	4.3	38.5℃
	12.35		50%	7.56	93.4	352	8238	3.8
	12.31		60%	9.78	120.4	412	8985	3.4
	12.27		70%	12.31	151.0	504	9766	3.3
	12.18		80%	16.96	206.6	662	10790	3.2
	12.07		90%	22.19	267.8	784	11772	2.9
	12.01		100%	24.38	292.8	826	12111	2.8
	12.86	APC8x6	40%	6.41	82.4	442	6553	5.4	39.3℃
	12.80		50%	9.09	116.4	607	7405	5.2
	12.79		60%	12.93	165.4	756	8315	4.6
	12.69		70%	17.57	223.0	919	9142	4.1
	12.56		80%	23.26	292.1	1046	10014	3.6
	12.38		90%	30.30	375.1	1284	10721	3.4
	12.28		100%	32.63	400.7	1351	10891	3.4
	12.38	APC9x6	40%	6.01	74.4	356	6418	4.8	39.8℃
	12.34		50%	8.49	104.8	538	7272	5.1
	12.27		60%	11.96	146.7	693	8133	4.7
	12.19		70%	16.14	196.7	861	8949	4.4
	12.08		80%	21.74	262.6	1066	9773	4.1
	11.93		90%	28.34	338.1	1195	10569	3.5
	11.86		100%	30.83	365.6	1283	10790	3.5
	16.28	APC8x6	40%	8.58	139.7	654	7679	4.7	40.7℃
	16.19		50%	12.66	205.0	836	8724	4.1
	16.07		60%	18.34	294.7	1009	9730	3.4
	15.84		70%	24.11	381.9	1241	10598	3.2
	15.65		80%	31.61	494.7	1469	11341	3.0
	15.47		90%	40.16	621.3	1650	12010	2.7
	15.43		100%	42.97	663.0	1662	12070	2.5
D3530- 1700KV(EVO)	12.65	7×5	40%	9.17	116.0	430	8664	3.7	39.6℃
	12.60		50%	12.77	160.9	522	9630	3.2
	12.52		60%	16.68	208.8	614	10457	2.9
	12.40		70%	21.83	270.7	762	11455	2.8
	12.23		80%	28.73	351.4	912	12538	2.6
	11.95		90%	37.08	443.1	1100	13430	2.5
	11.92		100%	40.81	486.5	1167	13725	2.4
	12.68	APC8x6	40%	9.29	117.8	502	8524	4.3	40.3 ℃
	12.61		50%	13.07	164.8	620	9477	3.8
	12.53		60%	17.41	218.1	737	10299	3.4
	12.42		70%	23.26	288.9	894	11222	3.1
	12.27		80%	31.38	385.0	1056	12150	2.7
	12.07		90%	41.31	498.6	1207	12963	2.4
	11.99		100%	44.51	533.7	1229	13224	2.3
	16.57	APC7x4	40%	10.37	171.8	545	11871	3.2	40.3 ℃
	16.49		50%	13.85	228.4	716	13091	3.1
	16.37		60%	17.67	289.3	869	14130	3.0
	16.14		70%	22.83	368.5	1046	15259	2.8
	15.92		80%	30.40	484.0	1255	16705	2.6
	15.65		90%	39.43	617.1	1474	17890	2.4
	15.64		100%	44.92	702.5	1577	18461	2.2
Nótaí: Is é an riocht tástála teochta ná teocht an dromchla mótair i throttle 100% agus an mótar ag rith 15 teocht timpeallachta 26 ℃
